Balluff BCS007L BCS M30T4M2-PPC30G-S04G Capacitive Level Sensor

Balluff BCS007L BCS M30T4M2-PPC30G-S04G Capacitive Proximity Switch Level Sensor PNP NO/NC programmable, 10 to 35V DC Operating voltage, 100 Hz Switching frequency, Switching distance adjustable Sensitivity

Specification/Additional Details

• Switching Mode : NO/NC
• Sensing Distance : Switching distance adjustable
• Brand : Balluff
• Output Type : PNP
• Supply Voltage : 10 to 35 V DC
• Switching Frequency : 100 Hz

• Body Material : Stainless steel
• Model : BCS007L BCS M30T4M2-PPC30G-S04G

• Installation : Non-flush

• Switching output : PNP NO/NC programmable

• Material sensing surface : PTFE

• Ambient temperature : -30 to 70°C

• IP rating : IP66

• Connection Style : Connector, M12x1-Male, 4-pin

• Dimension : Dia. 30 x 86.5 mm
