BCS0037 BCS M12T4D2- PSM40C-S04G Proximity sensor
Key Specifications
Sensor Type: Capacitive proximity switch
Dimensions: Ø 12 x 60 mm (M12 x 1 thread)
Sensing Range: 1 to 4 mm (adjustable sensitivity)
Operating Voltage: 12 to 35 VDC
Switching Output: PNP normally open (NO)
Switching Frequency: 100 Hz
Installation: Flush mounting
Connection: 4-pin M12 male connector
Housing Material: Stainless steel (1.4301)
Sensing Surface: PTFE
IP Rating: IP65
Operating Temperature: -30 °C to 70 °C
