BES 517-351-NO-C-03 Balluff sensor
Technical Specifications

• Sensor Type: Inductive proximity sensor
• Dimensions: 30 x 10.5 x 16.5 mm
• Mounting Style: Flush mounting (shielded)
• Sensing Range: 2 mm
• Switching Output: PNP, normally closed (NC)
• Switching Frequency: 2500 Hz
• Operating Voltage: 10...30 VDC
• Housing Material: PBT, GF20 (Polybutylene Terephthalate with glass fiber reinforcement)
• Sensing Surface Material: PBT, GF20
• Connection: 3.00 m PVC cable
• Operating Temperature: -25 to 70 °C
• IP Rating: IP65
• Approvals & Conformity: CE, UKCA, cULus, and WEEE
