Core Technical Specifications

• Sensor Type: Inductive Proximity
• Output Configuration: PNP, Normally Open (NO)
• Sensing Range: 1.5 mm
• Mounting: Flush (shielded installation)
• Housing Diameter: Ø 8 mm (smooth cylindrical barrel, D8.0)
• Housing Length: 45 mm

• Operating Voltage: 10 to 30 V DC
• Switching Frequency: 5,000 Hz (ideal for high-speed machinery)
• Connection Type: 5.00-meter PUR (Polyurethane) integrated cable
• Housing Material: High-grade Stainless Steel
• Sensing Face Material: PBT (Polybutylene terephthalate)
• Environmental Protection: IP68 rated (dust-tight and highly water-resistant)
• Operating Temperature Range: -40 °C to 85 °C
• Certifications: cULus, CE, and WEEE compliant

• BES: Balluff Inductive Sensor series
• G08EG: Smooth 8 mm stainless steel housing style
• PSC15B: PNP, Normally Open switching function with a 1.5 mm sensing distance
• BP05: Indicates a PUR cable connection with a length of 5 meters
