BES0086 (BES-M18MI-PSC50B-S04G) Balluff Sensor

BES0086 (BES-M18MI-PSC50B-S04G) Balluff Sensor

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

BES0086 (BES-M18MI-PSC50B-S04G) Balluff Sensor
Key Specifications

  • Sensor Type: Inductive proximity
  • Housing Style: M18x1 threaded barrel (Ø 18 x 66 mm dimensions)
  • Sensing Range: 5 mm (flush mountable installation)
  • Switching Output: PNP, normally open (NO)
  • Operating Voltage: 10 to 30 VDC
  • Switching Frequency: Up to 2,000 Hz
  • Connection Type: M12x1 male connector, 3-pin
  • Housing Material: Nickel-free coated brass (PBT sensing surface)
  • IP Rating: IP68
  • Operating Temperature: -40°C to 85°C
  • If you want, let me know:
    • What application or machine you are installing this on
    • If you need help finding compatible M12 connector cables or mounting brackets
    I can provide exact wiring diagrams or alternative part recommendations.
