BES00P7 (BES 516-324-G-E5-C-S49) Balluff sensor

BES00P7 (BES 516-324-G-E5-C-S49) Balluff sensor
Key Technical SpecificationsThe official Balluff Global Catalog details the exact electrical, dynamic, and mechanical capabilities of this sensor:

• Dimension: Ø 8 x 45 mm (M8x1 threaded housing)
• Sensing Range (\(S_{n}\)): 2.0 mm
• Installation: Flush / shielded mounting
• Switching Output: PNP Normally Open (NO)
• Switching Frequency: 5,000 Hz
• Operating Voltage: 10…30 V DC
• Electrical Connection: M8x1 male connector, 3-pin
• Housing Material: Robust Stainless Steel
• Sensing Surface: Polybutylene terephthalate (PBT)
• IP Rating: IP68 protection against dust and liquid ingress
• Ambient Temperature Range: Extreme temperature resilience from -40 °C to 85 °C
• Approvals & Conformity: CE, UKCA, cULus, and WEEE

Wiring Diagram ConfigurationSince this is a standard 3-Pin DC PNP Normally Open sensor with an M8 connector, it utilizes a generic industrial layout:

• Pin 1 (Brown): +10...30 V DC supply
• Pin 3 (Blue): 0 V (GND) reference
• Pin 4 (Black): Normally Open output signal (switches to positive when target is detected)
