BES00P7 (BES 516-324-G-E5-C-S49) Balluff sensor

BES00P7 (BES 516-324-G-E5-C-S49) Balluff sensor
Technical Specifications

• Sensor Type: Inductive proximity.
• Housing Dimensions: Ø 8 x 45 mm (M8x1 threaded barrel).
• Installation: Flush / shielded mounting.
• Sensing Range: 2 mm.
• Switching Output: PNP Normally Open (NO).
• Switching Frequency: 5000 Hz.
• Operating Voltage: 10...30 VDC.
• Connection: M8x1-Male connector, 3-pin.
• Housing Material: Stainless steel with a PBT sensing surface.
• Ingress Protection: IP68 rating (highly resistant to dirt and water).
• Operating Temperature: -40°C to 85°C.
• Approvals: CE, UKCA, cULus, WEE

Key Benefits

• Wear-Free Operation: Non-contact design eliminates mechanical wear and tear.
• High Durability: Short-circuit proof and highly resistant to contamination.
• Rapid Response: Outstanding 5kHz switching frequency fits high-speed automation needs.
