BES01U2 BESQ08ZC-PSC20B-S49G Balluff Sensor

BES01U2 BESQ08ZC-PSC20B-S49G Balluff Sensor
Key Specifications

• Sensing Range: 2.00 mm.
• Output Type: PNP Normally Open (NO).
• Housing: Rectangular block (8x8x59 mm) made of die-cast zinc.
• Sensing Surface: PBT (Polybutylene Terephthalate).
• Connection: 3-pin M8x1 male connector.
• Operating Voltage: 10...30 V DC.
• Switching Frequency: 3000 Hz.
• Protection Rating: IP67 (dust-tight and protected against temporary immersion).
• Operating Temperature: -25°C to 70°C.
