BES01WR BES R03KC-PSC30B-EP02 Inductive Proximity Sensor
Technical Specifications & Attributes
The technical profile details its performance capabilities:
- Sensing Range: 3 mm
- Installation Profile: Designed for flush mounting
- Output Configuration: PNP Normally Open (NO) switching output
- Switching Frequency: High-speed operation up to 3000 Hz
- Operating Voltage: 10...30 VDC
- Housing Dimensions: Ultra-compact block style measuring 30 x 10 x 6 mm
- Housing Material: Durable Polyamide (PA 6, GF30 glass fiber reinforced)
- Electrical Connection: 2.00-metre integrated Thermoplastic Polyurethane (TPU) cable
- Environmental Resistance: IP67 ingress protection rating
- Operating Temperature: Rated to perform reliably between -25 °C and 70 °C
- Safety Features: Integrated short-circuit, overload, and reverse polarity protection
