BES037K (BES 516-371-SA15-C-S49) Inductive proximity

BES037K (BES 516-371-SA15-C-S49) Inductive proximity

• Sensing Range: 2 mm
• Installation: Flush mounting (can be embedded directly in metal)
• Housing Dimensions: Ø 6.5 mm x 35 mm (smooth, cylindrical barrel body)
• Housing Material: Stainless steel with a PBT sensing surface
• Output Signal: PNP digital output with Normally Open (NO) switching logic
• Connection: Pre-equipped with a 3-pin M8 male connector
• Operating Voltage: 10…30 V DC
• Switching Frequency: Up to 1500 Hz (ideal for fast-moving manufacturing lines)
• Environmental Protection: Rated IP67 (dust tight and water resistant), operating between -25°C and 70°C
