BI1-EG05-AP6X Turck Inductive Proximity Sensor
Key Specifications

• Design & Size: M5 x 0.5 threaded barrel (5 mm diameter)
• Sensing Distance: 1 mm rated switching distance (flush mount)
• Operating Voltage: 10–30 V DC (3-wire DC)
• Output Function: PNP, Normally Open (NO) contact
• Switching Current & Frequency: 100 mA max switching current, 3 kHz switching frequency
• Connection Type: 2-meter gray attached cable
• Housing Material: Stainless steel (AISI 303 / 1.4305) with a PA6.6 active face
• Protection Class: IP67 (dust-tight and water-resistant)
• Operating Temperature: -25 °C to +70 °C
