BI4-M12-AP6X-H1141 high-precision, standard industrial inductive proximity sensor

BI4-M12-AP6X-H1141 high-precision, standard industrial inductive proximity sensor

Technical Specifications

• Sensing Range: 4 mm rated switching distance with an increased sensing range.
• Housing Size: M12 × 1 threaded barrel with a total length of 52 mm.
• Mounting: Flush / Embeddable installation, allowing it to be mounted level in metal without false triggering.
• Output Type: 3-wire DC, PNP sourcing with a Normally Open (NO) contact configuration.
• Electrical Connection: Integrated standard M12 × 1 male connector (Eurofast).
• Operating Voltage: 10 to 30 VDC with a maximum switching current of 200 mA.
• Switching Frequency: High-speed 2.0 kHz response frequency.
• Material & Build: Rugged chrome-plated brass housing with an IP67 environmental protection rating.
• Protection Circuits: Built-in short-circuit, overload, and complete reverse polarity protection.
