Bi8-M18E-VP6X-H1141 Proximity sensor

Bi8-M18E-VP6X-H1141 Proximity sensor
Key Technical Specifications

• Sensing Distance: 8 mm
• Mounting Type: Flush (embeddable)
• Operating Voltage: 10 to 30 VDC
• Output Function: 4-wire DC, Changeover (Complementary NO + NC contact), PNP output
• Switching Frequency: Up to 0.5 kHz (500 Hz)
• Connection Type: M12 × 1 male, 4-pin connector
• Housing Material: Chrome-plated brass (M18 × 1 thread)
• Enclosure Rating: IP67
• Temperature Range: -25°C to +70°C
