BLHM230KC-GFS Oriental Moto

BLHM230KC-GFS  Oriental Moto
Key SpecificationsAccording to documentation from Oriental Motor and Proax, the motor features:

• Output Power: 30 W (1/25 HP).
• Rated Voltage: 24 VDC.
• Rated Speed: 3000 r/min, with a speed control range generally between 100 to 3000 r/min depending on the driver.
• Protection Rating: IP65 (excluding the mounting surface and connectors), making it suitable for environments where dust or water splashes may occur.
• Shaft Type: Pinion shaft, which must be paired with a GFS gearhead.
• Frame Size: 2.36 in (60 mm).

Required ComponentsThis motor is sold as a standalone unit. To build a complete system, you typically need:

1. Gearhead: Compatible with GFS parallel shaft or hollow shaft flat gearheads (e.g., GFS2G20, GFS2G200FR).
2. Driver: Works with BLH Series 24 VDC drivers, such as the BLH2D30-K (Analog) or BLH2D30-KD (Digital).
