BN 325R SCHMERSAL

BN 325R SCHMERSAL
Key Features

• Type: Magnetic reed switch with a non-contact operating principle.
• Dimensions: 85 mm x 26 mm x 24 mm thermoplastic enclosure.
• Contacts: 1 internal reed contact.
• Actuation: Front-actuated by a designated magnet, with clear markings for the actuation surface and direction.
• Connections: Features a flat plug-in connector and a shielding plate (depending on the specific sub-variant like -1279 with pre-wired cables).

Technical Specifications

• Operating Temperature: -25 °C to +70 °C
• Protection Class: Varies by model configuration (IP00 for base terminal layouts up to IP67 for pre-cabled variants).
• Shock Resistance: Up to 50 g / 11 ms.
• Vibration Resistance: 10 to 55 Hz (amplitude 1 mm).

Common Applications

• Elevator door and position control
• Industrial automation assembly lines
• Non-contact monitoring of moving machine parts
