BV-D 63A (2 pole ) Limit sensor

BV-D 63A (2 pole ) Limit sensor
Core Specifications

• Brand: Mitsubishi Electric
• Rated Current: 63 Amps (The maximum continuous current it can safely handle)
• Mounting Type: Standard 35mm DIN Rail installation
• Current Type: AC

Key Model VariationsDepending on your exact phase system and sensitivity requirements, the BV-D 63A breaker comes in a few specific configurations:

• By Poles:
  • 2-Pole (2P): For single-phase residential/light commercial setups (Phase + Neutral).
  • 4-Pole (4P / 3+N): For three-phase electrical systems (3 Phases + Neutral).
• By Leakage Sensitivity:
  • 30mA: High sensitivity, primarily chosen for personal shock protection.
  • 300mA: Lower sensitivity, commonly used for equipment and fire hazard protection.
