BW50RAGU Molded Case Circuit Breaker (MCCB)

BW50RAGU  Molded Case Circuit Breaker (MCCB)

• Frame Size: 50 Ampere Frame (50AF).
• Number of Poles: Available in 2-pole or 3-pole configurations (denoted as 2P or 3P in full part numbers like BW50RAGU-3P050).
• Voltage Rating: Up to 690 V AC or 250 V DC.
• Breaking Capacity: 10 kA at 400V/440V AC.
• Tripping Mechanism: Thermal-magnetic or hydraulic-magnetic, depending on the specific model variation, for precise overload and short-circuit protection.
• Rated Current Options: Available in various ratings including 3A, 5A, 10A, 15A, 20A, 30A, 32A, 40A, and 50A.
• Global Compliance: Meets international standards including UL489 (480V requirements), IEC, EN, GB, JIS, and CSA.

• BW50RAGU-3P030: 3-Pole version rated for 30 Amps.
• BW50RAGU-3P050: 3-Pole version rated for 50 Amps.

• Compact Design: Unified dimensions allow easier integration into distribution boards.
• Field-Installable Accessories: Shunt trips, auxiliary switches, and alarm switches can be added by the user.
• Eco-Friendly: Conforms to the RoHS directive using lead-free solder.
