C200HE-CPU42 OMRON CONTROLLER

C200HE-CPU42 OMRON CONTROLLER
Key Specifications

• I/O Capacity: Supports up to 880 points when using expansion modules and backplanes.
• Memory:
  • User Memory (UM): 7.2K words (often listed as 8K).
  • Data Memory (DM): 6,000 words.
• Processing Speed: Executes basic instructions (LD) at a fast speed of 0.3 µs to 0.375 µs.
• Expandability: Can support a maximum of 2 expansion I/O racks and up to 10 special I/O units.
• Connectivity: Features one built-in RS-232C port for communication with external devices.

Physical & Environmental Details

• Mounting: Backplane mounting, typically into Omron’s C200H-BC series backplanes.
• Operating Temperature: Standard industrial range of 0°C to 55°C.
• Protection: Rated IP30 for ingress protection.
• Battery: Includes a battery backup system to ensure data retention during power interruptions.
