CA-61K-N SMT counter meter

CA-61K-N SMT counter meter
Key Specifications

• Digits: 6-digit dual display
• Presets: 1-preset level
• Input Type: Non-voltage (NPN) input signal (PNP versions, labeled CA-61K-P, are also available)
• Dimensions: Standard 72mm × 72mm panel cutout
• Sensor Power: Provides a built-in DC output for sensors (+12V, 100mA MAX)
• Operating Temperature: -10°C to 55°C
• Output Contact: 5A, 240VAC (resistive load)

Operational Features

• Key Protection: Front panel buttons can be locked to prevent accidental changes to set values.
• Up/Down Count Mode: Can be set to increment or decrement, and supports quadrature signals for bidirectional counting.
• Modifiable Settings: Features an easy-to-use "Mode" key to adjust the scaling factor, decimal point positioning, and other operational variables.
