CAM888-D1 Cam controller with mounting box
| Voltage | DC 10~30V |
| Frequency | 50 Hz |
| Communication | RS-485 |
| Current | 1A |
| Phase | Single |
| Operation Temperature | 0~40 Deg C |
| Angle Display | 0~359 Degree |
| Model Number | CAM888 |
| Stroke | 0~800 stroke/minute (360P/R) |
| Angle Sensor | 1 Deg |
| Setting Key | 4 micro switch keys(up,down,put in,enter) |
| Availability | In Stock |
- Master controller technology leader in the display panel to be installed separately.
MultiFunction
2-way brake output, programmable cutting cam 6 outputs, crop cam 6-channel output, 1 count reaches production output, the system indicates a normal output. Total of 16 outputs. Menu strokes / angle values are displayed: the stroke is greater than the continuous jog mode or 8 times / min, indicating the number of strokes, otherwise display angle value, other work displayed angle value.
Production counter display: 6 digits, the maximum count 999999.
Brake signal: 2-way redundant outputs.
- Vertex positioning: When can automatically compensate for the vertex positioning error.
- Cam settings: 6-channel programmable output clipping cam, cam cutting output 6 road.
- 1 channel count reaches production output.master controller technology leader in the display panel to be installed separately.
