CBSS5-8 SMT SCREW

CBSS5-8 SMT SCREW
Technical Specifications

• Thread Size (M): M5 (5mm nominal diameter).
• Length (L): 8mm total thread length.
• Head Type: Ultra-low head profile, measuring 1.5 mm or less in height.
• Drive Type: Hex socket (Allen key drive).
• Pitch: 0.8 mm (Standard metric coarse thread).
• Typical Materials: Available in high-tensile steel (SCM435 equivalent) or stainless steel (SUS304) depending on the exact material sub-code chosen.

Key Benefits

• No Countersinking: Unlike standard flathead screws, these ultra-low head cap screws do not require countersunk drilling to sit near-flush with the surface.
• Space Saving: Reduces the hardware clearance footprint by up to 80% compared to standard M5 socket cap heads, allowing for smaller, lighter devic
