CDHD-4D52AEC2 Servotronix drive

CDHD-4D52AEC2 Servotronix drive
Key Technical Specifications

• Power Rating: 400 W power capacity.
• Current Profile: 4.5 A continuous / 18 A peak RMS current input.
• Voltage Input: Single-phase or three-phase 120/240 VAC.
• Efficiency: Operates at an efficiency rating >96%.
• Enclosure Rating: Built with an IP20 industrial protection rating.

Core Features

• Advanced Control Loop: Features a high-frequency current loop design reaching 3-5 kHz for near-zero settling time.
• Vibration Suppression: Employs non-linear algorithms to eliminate mechanical resonance.
• Universal Feedback: Connects to almost any motor and supports multiple encoder feedback types.
• Safety & Diagnostics: Integrates a Safe Torque Off (STO) interface for urgent emergency stop circuits.
• Configuration Software: Programmed and tuned through the proprietary ServoStudio GUI interface.
