SMC CDJ2KB10-25Z-B Double Acting Air Cylinder

SMC CDJ2KB10-25Z-B Non-rotating Double Acting Single Rod Air Cylinder

The CDJ2KB10-25Z-B is a miniature, double-acting, non-rotating pneumatic air cylinder from the SMC CJ2 series. It has a non-rotating rod and a built-in magnet for auto-switch detection.

Breakdown of the part number

• C: A product from the CJ2K series of round-type air cylinders.
• DJ2K: Denotes a double-acting, non-rotating cylinder with a single rod.
• B: A basic, standard mounting type.
• 10: A bore size of 10mm.
• -25: A stroke length of 25mm.
• Z: Specifies that the cylinder has a built-in magnet for auto-switch capability.
• -B: Indicates that the ports are located perpendicular to the axis.

General characteristics

• Action: Double-acting, meaning air pressure is used to both extend and retract the piston.
• Rotation: Features a non-rotating rod design to prevent the piston rod from twisting during operation.
• Auto-switch: Compatible with auto-switches for position detection due to the built-in magnet.
• Mounting: Standard, basic mounting configuration.
• Cushioning: May be equipped with a rubber bumper or an air cushion.

Key specifications

• Manufacturer: SMC
• Action: Double-acting
• Bore Size: 10 mm
• Stroke: 25 mm
• Rod Type: Single rod, non-rotating
• Mounting: Basic type
• Cushioning: Rubber bumper
• Magnet: Built-in magnet for auto-switches
