SMC CDJ2B16-25Z-B Double-acting, Single-rod Air Cylinder

SMC Air Cylinder CDJ2B16-25Z-B Double Acting Single Rod CJ2-Z Series

The SMC CDJ2B16-25Z-B is a double-acting, single-rod air cylinder from the CJ2 Series. Its compact, round-body design includes a built-in magnet for auto-switching and uses a rubber bumper for cushioning.

Specifications

• Manufacturer: SMC Corporation
• Series: CJ2
• Operation: Double-acting
• Rod Type: Single rod
• Rod Tip: Male thread
• Bore Size: 16 mm
• Stroke Length: 25 mm
• Cushioning: Rubber bumper
• Auto Switch: Built-in magnet, with band-mounting style for switches
• Mounting: Basic mounting style
• Operating Pressure: 0.06 to 0.7 MPa
• Operating Temperature: -10°C to 60°C
• Tube Material: Standard (typically stainless steel)
