CDU10-25D cylinder SMC

CDU10-25D cylinder SMC
Key Technical Specifications

• Bore Size (Internal Tube Diameter): 10 mm
• Stroke Length: 25 mm
• Action: Double-acting, single rod (air extends and retracts the rod)
• Built-in Magnet: Yes (indicated by the "D" suffix, ready for auto-switch position sensing)
• Cushioning: Standard rubber bumpers on both ends
• Port Thread Type: Metric (M5 x 0.8)

Part Number Breakdown

• C: Built-in magnet for auto-switches
• DU: Free mount cylinder type (CU Series)
• 10: 10 mm bore size
• 25: 25 mm stroke length
• D: Double-acting configuration
