CDUJB20-10D SMC CYLINDER
Key Specifications

• Brand & Series: SMC CUJ Series (Model: CDUJB20-10D)
• Bore Diameter: 20 mm
• Stroke Length: 10 mm
• Action Type: Double Acting
• Mount Type: Through Hole / Free Mount
• Cushioning Type: Elastic / Rubber Bumper
• Body Material: Aluminium Alloy
• Piston Rod Thread: Female, M5 x 0.8 (Metric)
• Maximum Operating Pressure: 0.7 MPa
• Maximum Piston Speed: 500 mm/s
• Operating Temperature Range: -10°C to 60°C
• Weight: 61 g
