CDZ9-54P AC220V ssr relay

CDZ9-54P AC220V ssr relay
Key Specifications

• Type: Small electromagnetic intermediate relay (compatible with standard MY4 or HH54P 14-pin sockets).
• Pin Count: 14 pins arranged in a standard plug-in base configuration.
• Coil Voltage: AC 220V (the voltage required to energize the internal coil).
• Contact Capacity: Designed for multi-circuit control switching (typically 4-pole changeover or 4PDT contacts).

Difference from a Solid-State Relay (SSR)

• Mechanism: The CDZ9-54P uses a physical mechanical coil and moving metal contacts that click when activated. An SSR uses semiconductor chips (like triacs or thyristors) with no moving parts.
• Application: This mechanical relay is ideal for general industrial control cabinets and logic panels, whereas SSRs are used for silent, high-frequency, and rapid switching applications like heater control or motor dimming.

Would you like help finding a true solid-state relay (SSR) for your specific project, or do you need the pinout diagram for the CDZ9-54P?
