CGNY NY9ELE C16 (16Amp)
CGNY NY9ELE C16 (16Amp)
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Technical Specifications
The text printed on the device provides the following technical parameters:
- Brand / Manufacturer: CGNY (Guangdong Nanyang Electrical Appliance Co., Ltd. /
- Model Number: NC65ELE
- Tripping Curve & Rated Current: C16 (16 Amps, Type C tripping characteristic for moderate inductive surges)
- Rated Voltage & Frequency: 230V~, 50Hz
- Breaking Capacity: 4000A (4kA)
- Standards: GB/T16917.1 / GB/T16917.22
- Rated Residual Operating Current (\(I_{\Delta n}\)): 30 mA (Standard sensitivity for human shock protection)
- Rated Residual Non-operating Current (\(I_{\Delta n0}\)): 15 mA
- Break Time (\(t\)): \(\le \) 0.1 seconds
Core Functions
An RCBO provides three layers of critical electrical protection:
- Overload Protection: Safely disconnects the circuit if too many appliances are running simultaneously and draw more than 16 Amps.
- Short Circuit Protection: Instantly cuts power if a live wire directly touches a neutral or ground wire, preventing electrical fires.
- Earth Leakage Protection: Detects tiny current imbalances (as low as 30mA) escaping to the ground, which typically happens during an electrical shock or insulation failure [1].
Key Visual Interfaces
- Main Toggle Switch: The wide red lever turns the entire linked circuit ON or OFF manually.
- Test Button: The small square red button at the top is used to test the residual current functionality. Pressing it mimics a ground fault to ensure the internal mechanism trips correctly.
- Leakage Indicator: The small window labeled (Leakage Indicator) pops up or changes color if the device tripped specifically due to an earth leakage fault rather than a simple overload.
