CH9733P+ Load tester
CH9733P+ Load tester
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
CH9733P+ Load tester
Core Specifications
The technical specifications as detailed by international distributors include:
- Power Rating: 300W
- Voltage Ranges: 0–15V (Resolution: 0.1 mV, Accuracy: ±0.05%+0.03%FS) | 15V–150V (Resolution: 1 mV, Accuracy: ±0.05%+0.03%FS)
- Current Ranges: 0–3A (Resolution: 0.01mA, Accuracy: ±0.05%+0.05%FS) | 3–30A (Resolution: 0.1mA, Accuracy: ±0.05%+0.05%FS)
-
-
Key Specifications & FeaturesRatings: 0–150V voltage range, 0.1mA–30A current range, and up to 300W of power handling.Fast Charging Protocols: Built-in detection and emulation for PD (Powe Delivery), QC (Quick Charge), Huawei, OPPO, Vivo, Samsung, and MTK.Operation Modes: Supports CC (Constant Current), CV (Constant Voltage), CR (Constant Resistance), and CP (Constant Power) modes.Advanced Testing: Features overcurrent protection testing (OCP), maximum power point capture (Pmax), ripple measurements (Vpp/Ipp), and 50 kHz dynamic load mode.Interface & Data: Equipped with a 4.3-inch TFT high-definition color display, USB data recording, and SCPI protocol support for remote programmable control.
-
