CHUNT LIMIT SWITCH YBLX-3311

CHUNT LIMIT SWITCH YBLX-33/11

🔹 Product Description:

CHINT YBLX-33/11 is a high-quality industrial limit switch designed for precise position detection and motion control in automation systems. It is widely used in machine tools, conveyors, elevators, and automated production lines for controlling movement, direction change, and safety limit operations.

This switch ensures reliable performance, long service life, and accurate switching under various industrial conditions.

Key Features:

• Durable and robust industrial design
• High mechanical strength for long operational life
• Precise and reliable switching performance
• Compact size with easy installation
• Suitable for harsh industrial environments
• Available with roller/plunger type actuator (as per model)

  Technical Specifications:
  • Model: YBLX-33/11
  • Brand: CHINT
  • Rated Voltage: AC 380V / DC 220V
  • Frequency: 50/60 Hz
  • Contact Type: 1 NO + 1 NC
  • Rated Current: AC-15 up to 0.8A / DC-13 up to 0.15A
  • Protection Degree: IP52 (dust & drip protection)
  • Operating Temperature: -5°C to +40°C
