- CJ1W-OD231 Omron Europe
- Output Type: NPN (sinking) transistor outputs.
- Number of Outputs: 32 points (organized as 16 points/common, 2 circuits).
- Rated Voltage: 12 to 24 VDC.
- Operating Load Voltage Range: 10.2 to 26.4 VDC.
- CJ1W-OD231 Omron Europe
- Maximum Load Current: 0.5 A/point, 2.0 A/common, 4.0 A/Unit.
- Response Time: Max. 0.1 ms (ON) and max. 0.8 ms (OFF).
- I/O Connection Type: FCN connector (plug not included).
- Short-circuit Protection: Not included in this specific model (other models with this feature are available).
- Mounting Type: DIN Rail mount.
- Dimensions (H x W x D): 90 mm x 20 mm x 66.5 mm.
- Internal Current Consumption: Max. 140 mA at 5 VDC.
- Weight: Max. 70 g.
