CJX2-1210 Chint contactor
Key Specifications

• Model Type: CJX2-1210 (3 Main Poles + 1 Normally Open Auxiliary Contact)
• Rated Current (AC-3): 12A (at 380V)
• Conventional Thermal Current (Ith): 18A to 20A
• Rated Insulation Voltage (Ui): Up to 660V/690V AC
• Controlled Power (Pe): 3kW at 220V, 5.5kW/7.5kW at 380V/660V
• Mounting: Standard 35mm DIN Rail or screw mounting with
• Common Coil Voltages: Available in 24V AC, 110V AC, or 220V/230V AC options

Applications

• Motor Control: Frequent start, stop, and long-distance switching of 3-phase AC electric motors.
• Industrial Equipment: Used in machinery like commercial ovens, bakery equipment, and pneumatic sealers.
• Power Distribution: Can be paired directly with thermal overload relays to create electromagnetic motor starters.
