CJX2-4011 AC magnetic contacto

CJX2-4011 AC magnetic contacto
Core SpecificationsThe basic electrical and physical properties of the standard CJX2-4011 contactor are outlined below:

• Rated Operational Current (Ie): 40A (AC-3, 380V/415V)
• Conventional Thermal Current (Ith): 60A
• Main Pole Configuration: 3 Phase / 3 Pole
• Auxiliary Contacts: 1NO + 1NC
• Rated Insulation Voltage (Ui): 660V to 690V
• Coil Voltage Options: Most commonly available with a 220V AC or 415V AC 50/60Hz control coil, though variants range from 24V to 380V.
• Mounting: Standard 35mm DIN Rail or screw mounting.
• Contact Material: High-grade silver alloy contact points for superior electrical conductivity and arc-resistance.
