CLF-3000HH SMT Screw driver

CLF-3000HH SMT Screw driver
Core Specifications

• Torque Range: 0.03 – 0.15 N.m (0.3 – 1.5 kgf.cm)
• Rotation Speed: 560 to 1,000 RPM (two-speed settings)
• Screw Sizes: 1.0 – 2.0 mm (Tapping screws: 1.0 – 1.7 mm)
• Drive Size: 4mm HIOS H4 shank
• Motor Type: Brushed DC
• Operation: Lever start / Remote start (ideal for XY robots and automated lines)

Key Features

• Automation Ready: Designed to be easily integrated into automated assembly lines and robotic arms for uniform, repeatable screw tightening.
• Ultra-Low Torque: Allows for the careful tightening of small, delicate components without stripping the threads or cracking circuit boards.
• Safety: Operates on low-voltage direct current (DC), making it safe for industrial SMT and ESD-sensitive (Electrostatic Discharge) environments.
