SICK CM Series CM30-25NAP-KW1 Capacitive Proximity Sensor 6028413

CM30-25NAP-KW1 SICK Capacitive Proximity Sensor, CM30-25NAP-KW1 Sick Proximity Switch 25mm Range

The CM30-25NAP-KW1 is a capacitive proximity sensor from the SICK CM series, designed for industrial applications. It can detect objects at a range of 4 mm to 25 mm and is housed in a non-flush, threaded, plastic barrel with an IP67 rating.

Specifications

• Manufacturer: SICK
• Series: CM
• Part number: CM30-25NAP-KW1 (also 6028413)
• Sensor type: Capacitive proximity sensor
• Sensing range: 4 to 25 mm
• Mounting type: Non-flush
• Housing: Threaded barrel, M30 x 1.5, made of PBT plastic
• Wiring: 2-wire AC
• Output function: Normally open (NO) or normally closed (NC)
• Connection: 2-meter PVC cable
• Supply voltage: 20–250 V AC
• Protection rating: IP67 (protected from dust and immersion in water)
• Operating temperature: -25 °C to +80 °C
• Adjustment: Potentiometer for sensitivity
