CP1L-L20DT-D Omron Logic controller
Technical Specifications
- Power Supply: 24 VDC
- Total Built-in I/O: 20 points (12 Inputs / 8 Outputs)
- Input Type: 24 VDC inputs (includes 4 high-speed 100 kHz counter axes)
- Output Type: NPN Transistor / Sink type (0.3 A, includes 2 pulse 100 kHz axes for positioning)
- Memory Capacity: 5K steps program memory + 10K words data memory
- Built-in Connectivity: 1 x Peripheral USB port (for programming and monitoring)
- Mounting Type: DIN Rail
Model Code Breakdown
- CP1L: High-performance compact PLC series.
- L: "L" Type CPU unit (scale classification).
- 20: Total number of built-in digital I/O points.
- D: DC input type.
- T: Transistor output (NPN/Sink).
- -D: 24 VDC power supply requirement.
Key Benefits
- High-Precision Positioning: Features built-in 2-axis pulse outputs and 4-axis high-speed counters, making it highly effective for small-scale motion and motor control.
- Expandable Architecture: Supports optional plug-in boards for additional RS-232C/RS-485 serial communication or analog I/O without expanding the physical footprint.
- Code Compatibility: Uses the same foundational architecture as Omron's premium CJ1, CP1H, and CS1 series, meaning ladder logic programs can easily scale up if your machine design grows.
- Advanced Programming: Supports Structured Text (ST) language alongside traditional ladder logic, making complex mathematical operations straightforward to write
