CP1W-20EDTdigital I/O expansion unit

CP1W-20EDT digital I/O expansion unit
Technical Specifications

• Module Type: Digital I/O Expansion Unit
• Digital Inputs: 12 inputs (24 V DC)
• Digital Outputs: 8 transistor outputs (NPN-sinking or PNP-sourcing depending on exact suffix variant like CP1W-20EDT vs CP1W-20EDT1)
• Output Current: 0.3 A per output
• Power Supply: Uses internal 24 V DC bus / external connection parameters specific to the unit layout
• Mounting Style: DIN Rail mount

Key Features

• Expands total I/O capacity of compatible Omron CP1 series controllers.
• Compact dimensions designed for space-saving control panel integration.
• Screw terminal block connections for secure wiring.
