CP30-BA-2P 1M 5A mitsubishi

CP30-BA-2P 1M 5A mitsubishi
Technical Specifications

• Poles: 2-Pole (2P) configuration
• Current Rating: 5 Amp (5A)
• Voltage Rating: Up to 250V AC / 125V DC (AC/DC common use)
• Trip Speed/Curve: Medium-speed type (M-Curve)
• Short-Circuit Breaking Capacity: 2.5 kA
• Mounting Type: 35mm DIN-rail mount

Design & Features

• Compact Width: Slim design measuring 17.5mm width per pole.
• Terminal Protection: Standard equipped with an open/close compact finger-safe terminal cover (IP20 compliant).
• Safety Standards: Recognized and compliant with UL 1077, CSA C22.2 No.235, EN/IEC 60934, and CE standards.
