CQM1-OC222 Omron Output Module

CQM1-OC222 Omron Output Module

• Output Type: Relay (utilises internal G6D-1A subminiature relays).
• Number of Outputs: 16 points sharing a single common line.
• Max Switching Voltage: 250 V AC or 24 V DC.
• Max Switching Current: 2 A per point (with a total unit limitation of 8 A per unit).
• Min Switching Capacity: 10 mA at 5 V DC.
• Internal Power Consumption: 850 mA maximum at 5 V DC from the PLC backplane.
• Response Time: 5 ms maximum off-delay time.
• Relay Service Life: 20 million mechanical operations; 300,000 electrical operations under a resistive load.
• Connection Type: Standard removable screw terminal block.
• Mounting Type: Integrated DIN rail mounting mechanism.

• Compact Rackless Design: Plugs directly into adjacent modules without needing a bulky backplane rack, making it ideal for tight control panel enclosures.
• LED Status Indicators: Features front-facing physical LEDs for each of the 16 channels to allow rapid troubleshooting and real-time visual logic checking.
• High Power Capacity: The relay outputs function as dry contacts capable of handling higher currents (up to 2 A) directly compared to traditional transistor output modules
