CR2LS-10  Fuji Electric Fuse
Key Specifications & Features

• Manufacturer:
• Model Number:(also available in a UL-recognized variant as CR2LS-10/UL
• Rated Current: 10 A
• Rated Voltage: 250 V AC (with DC variants like CR2LS-10/UL rated for up to 250V/400V DC depending on spec)
• Breaking Capacity / Interrupt Rating: 100,000 A (100 kA) at 250 V AC
• Power Loss: 1.2 W
• Dimensions: 78 mm × 34.5 mm × 27 mm (barrel-shaped with offset/L-shaped bladed design for screw mounting)
• Primary Applications: Safeguarding sensitive power semiconductor components such as silicon diodes, thyristors, and semiconductor-based inverters or transformer-rectifiers.
