Metrol CS-Touch Switch CSP087A-A Limit Switch

Metrol CS-Touch Switch CSP087A-A 2.8 mm Stroke DC5V - DC24V Contact rating,
Metrol CSP087A-A CS-Touch Switch Position Switch

Specification/Additional Details

• Contact Configuration : NO
• Brand : Metrol
• Model : CSP087A-A
• Product Type : CS-Touch Switch
• Overall length : 52.8mm
• Outer diameter : M8x0.75
• End shape : Round shape

• Stroke : 2.8mm

• Pretravel : About 0.3mm

• Contact force : 1N

• Case material : SUS303

• Contact material : SUS HRC50

• Cable direction : Straight

• Operating temperature range : 0°C-80°C

• Contact rating : DC5V - DC24V

• Steady Current : 10 mA or less
