CXSM6-20 Pneumatic Cylinder
Core Technical Specifications
The standard operational parameters for this model include:
- Bore Diameter: 6 mm
- Stroke Length: 20 mm
- Actuation: Double acting, dual-rod
- Bearing Type: Slide bearing
- Non-rotating Accuracy: \(\pm 0.1^{\circ }\)
- Body Material: High-quality aluminium alloy
- Operating Temperature: 5°C to 60°C
- Fluid Type: Non-lubricated, filtered compressed air
Key Structural Features
- High Non-Rotational Precision: The dual-rod configuration naturally distributes side loads equally, providing excellent linear tracking without requiring external guides.
- Flexible Multi-Directional Mounting: The outer housing allows direct mounting from three separate directions, and workpieces can be fastened to three individual faces for versatile integration.
-
Integrated Sensor Recesses: Built-in slots accommodate reed or solid-state auto-switches (e.g., standard models like the
Z73), enabling reliable magnetic piston position sensing. - Stroke Adjustment: Includes built-in buffer cushioning and an adjustable stroke function capable of shortening the standard stroke by up to 5mm.
