D2425-B Sensata-Crydom | Solid State Relays (SSR)

D2425-B Sensata-Crydom | Solid State Relays (SSR)
Technical Specifications

• Load Current Rating: 25 A
• Operating Load Voltage Range: 24 V to 280 V AC
• Control Input Voltage Range: 3 V to 32 V DC
• Contact Configuration: SPST-NC (Normally Closed)
• Output Type: SCR (Silicon Controlled Rectifier)
• Switching Type: Zero Crossing
• Dielectric Isolation Voltage: 4000 V (RMS)
• Termination Style: Screw Terminals
• Safety & Regulatory Approvals: UL listed, CSA approved, VDE, and CE compliant

Key Structural Features

• Heavy Industrial Reliability: Built with a direct bond copper substrate to facilitate optimal thermal dissipation.
• Physical Integrity: Features a redesigned housing incorporating anti-rotation barriers to ensure secure screw terminal installation.
• Environmentally Conscious Construction: Utilizes an epoxy-free design layout.
