D2F-FL Omron MICRO SWITCH
Key Specifications

• Manufacturer: Omron Electronic Components / Aratas
• Switch Type: Ultra-subminiature snap-action microswitch
• Circuit Configuration: SPDT (Single Pole Double Throw)
• Actuator Type: Hinge lever
• Contact Rating: 1A at 125 VAC / 0.5A at 30 VDC (or 3A variants depending on specific sub-model)
• Operating Force (OF): ~0.74 N (75 gf)
• IP Rating: IP40
• Operating Temperature: -40°C to 85°C
• Mechanical Life: 1,000,000 operations
• Electrical Life: 30,000 operations
