D4B-4111N OMRON LIMIT SWITCH

D4B-4111N OMRON LIMIT SWITCH
Key Technical Specifications

• Contact Form: 1NC/1NO with snap-action operation.
• Safety Features: Equipped with a direct opening mechanism (NC contacts only) to ensure contact separation even if a fault like contact welding occurs.
• Actuator Type: Roller lever with a 17.5 mm diameter resin roller and a 31.5 mm radius lever.
• Conduit Size: M20 (indicated by the "4" in the model number D4B-4111N).
• Ingress Protection: IP67 rated, making it dust-tight and waterproof.
• Current/Voltage Rating: 10 A at 250 VAC or 6 A at 30 VDC.
• Operating Temperature: Wide range from -40°C to 80°C.
• Durability: Mechanical life of at least 30 million operations.
