D4C-4402 Omron Limit sensor

D4C-4402 Omron Limit sensor
Key Specifications

• Actuator Type: Roller plunger (oblong metal roller, Ø12mm × 4.4mm)
• Electrical Rating: Micro-load type (0.1 A at 125 VAC / 0.1 A at 30 VDC)
• Output Configuration: SPDT (Single Pole Double Throw)
• Ingress Protection: IP67 (Dust-tight and waterproof protection conforming to IEC standards)
• Cable Type: 3-meter pre-wired VCTF oil-resistant vinyl cabtire cable
• Operating Speed Range: 0.1 mm to 0.5 m/s
• Mechanical Durability: 10 million operations minimum
• Operating Temperature: -10°C to 70°C (with no icing)
