Omron D4MC-5020 Limit Switch
Omron Roller Plunger Limit Switch D4MC-5020 Micro Momentary Switch Panel Mount 1NC+1NO
The Omron D4MC-5020 Limit Switch is a semi-compact, enclosed limit switch featuring a roller plunger actuator, an IP67 protection rating, and SPDT (Single Pole Double Throw) contacts. It is primarily used in industrial automation for reliable position detection in demanding environments.
Key Specifications
| Manufacturer | Omron |
| Actuator Type | Panel Mounted Roller Plunger |
| Contact Configuration | SPDT (1 NO, 1 NC) |
| IP Rating | IP67 (Dust tight, waterproof up to 1m immersion for 30 min) |
| Current Rating | 10A (AC) / 6A (DC) |
| Voltage Rating | Max 480V AC / 250V DC |
| Operating Force | 5.88 N (600 gf) |
| Electrical Life | 500,000 operations minimum |
| Mechanical Life | 10 million operations minimum |
| Termination Style | Screw Terminals (M4 bind small screw) |
| Dimensions | 70 mm (L) x 47 mm (W) x 21.7 mm (D) |
| Operating Temperature | -10°C to +80°C |
| Certifications | UL, CSA, CCC |
