D4N-1226 Omron Automation and Safety

D4N-1226 Omron Automation and Safety

🛠️ Key Technical Specifications

• Actuator Type: Metal roller lever with a \(\phi 17 \times 6\) bearing roller (Radius: R26).
• Contact Form: 2NC (Double-Break, Snap-Action mechanism).
• Electrical Rating: 3A at 240V AC.
• Conduit / Connection Size: Pg13.5.
• Operating Force (OF): 5 N maximum.
• Release Force (RF): 0.5 N minimum.
• Environmental Protection: Rated at IP67 (dust-tight and water immersion protection).
• Mechanical Durability: Minimum of 15,000,000 operations.
• Operating Temperature: Wide deployment range from -30°C to +70°C.

• D4N: Safety Limit Switch Product Family.
• 1: 1-conduit body housing design.
• 2: 2NC contact configuration (Snap-action).
• 26: Roller lever actuator specifically equipped with a smooth-glide bearing roller.
