D4NL-1DFA-BS Omron Automation and Safety D4NL Series guard-lock safety-door switch.
D4NL-1DFA-BS Omron Automation and Safety D4NL Series guard-lock safety-door switch.
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
D4NL-1DFA-BS Omron Automation and Safety D4NL Series guard-lock safety-door switch.
Key SpecificationsAccording to sources like DigiKey and Omron Europe, the Omron D4NL-1DFA-BS has the following specifications:
| Type | Description |
|---|---|
| Product Type | Safety Door Switch with Solenoid Lock |
| Manufacturer | Omron Automation and Safety |
| Locking Mechanism | Mechanical lock system with 24 V DC solenoid release method |
| Contact Configuration | DPST-NC x 2 (2 Normally Closed door monitor contacts, 2 Normally Closed lock monitor contacts) |
| Rated Voltage | 240 VAC, 250 VDC |
| Current Rating | 3A (AC), 270mA (DC) |
| Holding Force | 1,300 N or more (approx. 133 kgf) |
| Termination Style | Screw Terminal |
| Conduit Thread Size | Pg13.5 |
| Ingress Protection (IP) Rating | IP67 - Dust Tight, Waterproof |
| Features | Status Indicator (Orange LED for 10 to 115 VAC/VDC) |
| Housing/Head Material | Plastic head |
| Approvals | CCC, CE, cULus, TUV, EN, GB(CCC) |
