D4NL-2CFG-Z-F Omron Guard Lock Safety-door Switch

• D4NL-2CFG-Z-F Omron Guard Lock Safety-door Switch

• Switch Type: Tongue-operated safety door switch with a solenoid locking mechanism.
• Rated Voltage: 240 VAC.
• Current Rating: Typically 3A (240 VAC).
• Contact Configuration: Commonly configured as 2NC (Safety) + 1NC/1NO (Door monitor/Lock monitor).
• Locking Force: Features a minimum key holding force of 1,300 N.
• Environmental Protection: IP67 rated (waterproof and dust-tight).
• Physical Properties:
  • Dimensions: Approximately 86mm (W) x 95mm (H) x 35mm (D).
  • Weight: ~600g.
  • Color: Typically Black and Red body.

Usage & Features

• Safety Interlocking: Designed to ensure that protective doors remain locked until hazardous motions have stopped.
• Installation Flexibility: Supports multiple mounting directions for the operation key.
• Microload Support: Can be used for standard industrial loads or microloads.
